Material

Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy

Shape

Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square,Bar,Pipe,Sheet

Grade

Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L

Others:253Ma,254SMo,654SMo,F50(UNSS32100)F60,F61,F65,1J22,N4,N6 etc

Alloy : Alloy 20/28/31

Hastelloy:HastelloyB/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g

Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617,Hastelloy C,

Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602,

Hastelloy C-276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665

Haynes: Haynes 230/556/188

Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20

Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851,

Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 / UNS N06600 / DIN W. Nr. 2.4816

Incoloy: Incoloy 800/800H/800HT/825/925/926;

GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044

Monel: Monel 400/K500/R405

Nitronic: Nitronic 40/50/60;

Nimonic: Nimonic 75/80A/90/A263 ;

Specification

Wire: 0.01-10mm

Strip: 0.05*5.0-5.0*250mm

Bar: φ4-50mm;Length 2000-5000mm

Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm

Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm

Product

Characteristics

1.According to the preparation process can be divided into deformation superalloys,

casting superalloys and powder metallurgy superalloys.

2.According to the strengthening mode, there are solid solution strengthening type, precipitation strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc..

Standard

GB,AISI,ASTM,DIN,EN,SUS,UNS etc

Inspection

ISO,SGS,BV and so on.

Application

High temperature components such as turbine blades, guide vanes, turbine disks,

high pressure compressor disks,machine manufacturing

and combustion chambers used in the manufacture of aviation, naval and industrial gas turbines

Packaging

1. cases packed in wooden cases

2. paper packaging

3. plastic packing

4. foam packaging

Packaging according to customer requirements or products

Grade

Ni%

Cu%

Fe%

Mn%

C%

Si%

S%

Monel 400

Min 63

28-34

Max 2.5

Max 2.0

Max 0.30

Max 0.50

Max 0.024

Weld tube

Outer diameterΦ4.76-135mm,Wall Thickness0.25-4.00mm,Length:≤35000 mm

Seamless Tube

Outer diameterΦ3-114mm,Wall Thickness0.2-4.5mm

Application

Petrochemical equipment, heat exchanger, flue gas desulfurization equipment, fluid chemical pump, fluorine chemical industry

Properties

Metric

Imperial

Tensile strength

740.5 MPa

107400 psi

Yield strength

347 MPa

50300 psi

Elastic modulus

205 GPa

29700 ksi

Elongation at break

67%

67%

Properties

Metric

Imperial

Density

8.89 g/cm3

0.321 lb/in3

Melting point

1325 °C

2417 °F
